Drop-in Integral Apron Bathtub One Piece Acrylic Soaking White Rectangular Alcove Bathtub for Project

Share to:

60" Alcove Acrylic Soaking Bathtub, Drop-in Integral Apron, ASTM Compliant for Multi-Family Hotel Projects | Project Tub Supplier

This 60-inch standard alcove acrylic bathtub is engineered for North American multi-family and hospitality construction projects, fully meeting ASTM building code requirements.
It features an integral apron and pre-installed tile flange for seamless wall integration, with a one-piece seamless structure that eliminates leakage risks and speeds up on-site installation.
Factory direct bulk supply with palletized packaging, supporting left/right drain customization and uniform batch quality. Perfect for hotel, apartment and senior living facility new construction and renovation.

Availability:

Quantity:



Inquire Add to Basket

Model:
AB6032A
Brand:
Custom Made

Product Description

Acrylic_Bathtub (7)

Model Number:	AB6032	Feature:	drop-in integral apron bathtub
Type:	Bathtub	Size:	60" × 32" × 20"/Custom Made
Material:	Acrylic	Structure:	3-layer composite: 5mm acrylic + fiberglass mesh + steel reinforced backing
Water Depth:	14-3/8" soaking depth	Load Capacity:	400 lbs dynamic weight capacity
Drain Position:	Right-hand standard, left-hand optional	Waterproof Feature:	Pre-installed 3-sided tile flange for wall waterproofing
Installation:	Alcove / drop-in with integral front apron	Safety & Compliance:	ASTM E84 Class A fire rating, ASTM D4060 abrasion tested, NSF/ANSI 372 lead-free drain
Bulk Packaging:	6 units per pallet, export shockproof packaging	Project Service:	Custom drain position, neutral packaging, batch dimension consistency guarantee

Acrylic_Bathtub (1)

Code-Compliant Design – Matches North American Standard Alcove Construction

Designed to fit the universal 60-inch alcove layout widely used in US and Canadian residential and commercial buildings, this bathtub seamlessly integrates with standard wall framing and countertop configurations, no custom structural modification needed on site.The integrated tile flange runs along three sides of the tub, creating a waterproof seal against wall tiles and preventing moisture intrusion, fully complying with local building waterproofing codes. It supports both right-hand and left-hand drain configurations to match different bathroom plumbing layouts.

Acrylic_Bathtub (12)

Military-Grade Construction‌

3-Layer Composite:‌ 5mm glossy acrylic + fiberglass mesh + steel-reinforced Americast™ backing

Performance Features:‌

500-cycle scratch resistance (ASTM D4060 tested)

1.2x noise reduction vs. enameled steel tubs

Right-hand drain pre-configured for North American plumbing

Acrylic_Bathtub (5)

Turnkey Installation Solutions‌

• Integrated wall-mount filler recess (compatible with Delta/Pfister/Moen rough-ins)

• Tap-action drain stopper included (optional left-hand drain for +$28/unit)

• Ships palletized (6 units/pallet) with corner protectors for job site delivery

Acrylic_Bathtub (10)

Commercial-Grade Durability for High-Occupancy Properties

-Three-layer reinforced structure: 5mm high-gloss acrylic surface + fiberglass reinforcement + steel-backed support base, with 400lbs dynamic load capacity, suitable for long-term high-frequency use in hotels and rental apartments.-Scratch and stain resistant acrylic surface passes ASTM D4060 abrasion test, easy to clean and maintain, with excellent heat retention for comfortable soaking experience.-Class A fire rating per ASTM E84 standard, meeting commercial building fire safety requirements for public accommodation properties.

Acrylic_Bathtub (4) Acrylic_Bathtub (2)

SIZE

图(4)

Project-Optimized Bulk Delivery & Installation

- Pre-configured drain and overflow assembly reduces on-site plumbing work, cutting installation time per unit by 30% compared to standard models, ideal for large-scale project schedules.-Palletized shipping with 6 units per pallet, reinforced corner protectors and shock-absorbent packaging, designed for direct job site delivery with low breakage rate.-Uniform batch quality with consistent dimensions and finish across all units, supporting neutral packaging and custom brand labeling for property developers and plumbing contractors.

FAQ：

Q1: Does this tub fit standard 60-inch alcove framing in North American buildings?

A: Yes. It is designed to the universal 60-inch alcove dimension standard, matching most residential and commercial bathroom framing layouts in the US and Canada, no custom wall modification required.

Q2: What is the function of the tile flange, and does it help with waterproofing?

A: The pre-installed 3-sided tile flange creates a sealed overlap with wall tiles, preventing water from seeping behind the tub. It is designed to meet North American bathroom waterproofing building codes.

Q3: Can we choose left-hand drain for our project plumbing layout?

A: Yes. Right-hand drain is standard, and left-hand drain configuration is available for bulk project orders to match different bathroom plumbing designs.

Q4: How is the tub packaged for job site delivery?

A: It is delivered palletized with 6 units per pallet, reinforced with corner protectors and shock-absorbent packaging to minimize breakage during transportation and on-site handling.
